Funciones
Circuitos de clase D de rango completo de 4 canales
Capacidad de carga estéreo de 2 Ω
Entradas RCA de bajo nivel
Entradas de alto nivel
Crossover seleccionable: HPF/LPF/Full
Salidas puenteables @ 4Ω de carga
Compatible con cualquier altavoz de 4/1Ω
Diseño de mosfet de alta eficiencia
Sistema de gestión del calor
Características técnicas
4 x 150 vatios @ 4 Ω estéreo
4 x 300 vatios @ 2 Ω estéreo
2 x 600 vatios @ 4 Ω puenteados
Compatibilidad: 2 Ω estéreo
THD y potencia nominal <0.5%
Ancho de banda (-3 dB) - 18Hz- 22KHz
Factor de amortiguación (1k Hz @ 4Ω) - 100
Relación señal/ruido >90dB
Sensibilidad de entrada: 285Mv - 6V
Pendiente del filtro cruzado en estéreo - 12dB
Canal 1-2 Rango de filtros HP - 40Hz - 3KHz
Rango de filtro LP canal 1-2 - 40Hz - 3KHz
Canal 3-4 Gama de filtros HP - 40Hz - 3KHz
Rango de filtro de canal 3-4LP - 40Hz - 3KHz
Dimensiones
L-6,05 pulgadas (153,7 mm)
H-2,33 pulgadas (59,2 mm)
W- 5,53 pulgadas (140,5 mm)
The Quantum QEA500.4, QEA800.4, QEA800.2 are equiped with a built in variable crossover network allowing you to select the crossover function and frequency for each the front channels or rear channels of the amplifier independently.
Class A/B Circuitry
2 Ohm Load Stereo Capability
Audiophile Grade Components
Variable Low/ High Pass Crossover
High Efficiency Mosfet Design
QSINK Heat Management System
Technical information
2 Ohms VERSION
Nominal Power @14.4VDC2 Ohms: 800W RMS (4 x 200W RMS)4 Ohms: 544W RMS (4 x 136W RMS)2 Bridged Channels4 Ohms: 800 W RMS (2 x 400W RMS)
Number of Channels
04
Input Sensitivity
(RCA): 4V (min.) / 250mV (max.)(WIRE): >10V (min.) / 3V (max.)
Signal to Noise Ratio
>90dB
Frequency Response
10Hz ~ 20KHz (-3dB)
Crossover high pass (HPF)
90Hz (-12dB/8ª) Fixed
Crossover low pass (LPF)
90Hz (-12dB/8ª) Fixed
Input Impedance
10K Ohms (RCA)
Output Impedance
2 Ohms
protection system
Output Short Circuit
Minimum Supply Voltage
9VDC
Maximum Supply Voltage
16VDC
Consumption at rest
0.9A
Maximum music consumption
38A
Maximum consumption in sinusoidal signal
76A
Dimensions (WxHxD)
5.43" x 1.89" x 6.89" (138 x 48 x 175mm)
Weight
1.91lb (0.87Kg)
EAN
7898556849043
Description
The TS 400×4 is designed with the highest performance to suit most types of car audio systems. It is multichannel, with 4 channels of 100 Watts RMS, with a maximum power of 400 Watts RMS at 2 Ohms. The TS 400×4 is a FULL RANGE amplifier. It features thermal and short-circuit protection, plus LED indicator and crossover.
Description
The Taramps MD 3000.1 in the 1 Ohm version has been carefully designed with the highest technology, offering high efficiency and performance for various types of car audio systems. This amplifier covers the whole frequency range, that is to say that it is a FULL RANGE module. It is classified as mono and has a channel with a maximum power of 3000-Watts RMS. Welcome to Taramps audio world.
Description
The Taramps HD 3000 is a 1 Ohm, single-channel amplifier capable of delivering 3000 Watts RMS of power. It is compatible with all types of speakers, drivers and tweeters.
* This product comes with an M1 LED Monitor
Technical information
2 Ohms VERSION
Nominal Power @14.4VDC2 Ohms: 1200W RMS (4 x 300W RMS)4 Ohms: 740W RMS (4 x 185W RMS)2 Bridged Channels4 Ohms: 1200 W RMS (2 x 600W RMS)
Number of Channels
4
Input Sensitivity
(RCA) - 4V (min.) / 250mV (max.)(WIRE) - >10V (min.) / 3V (max.)
Signal to Noise Ratio
>90dB
Frequency Response
(FULL RANGE) - 8Hz ~ 25KHz (-3dB)
Crossover high pass (HPF)
90Hz (-12dB/8ª) Fixed
Crossover low pass (LPF)
90Hz (-12dB/8ª) Fixed
Input Impedance
10K Ohms (RCA)
Minimum Supply Voltage
9VDC
Maximum Supply Voltage
16VDC
Consumption at rest
0.9A
Maximum music consumption
55A
Dimensions (WxHxD)
5.43" x 1.89" x 9.84" (138 x 48 x 250 mm)
Weight
2.73 lb (1.24 Kg)
