Technical Specifications: Inputs MAIN IN ( RCA) and HI-INPUT ( Speaker Wire) Outputs SUB OUT / FRONT and REAR Audio Controls INPUT LEVEL / FADER / 7 BAND EQ +/- 12 dB Level Bass Knobs SUB LEVEL / LPF FREQUENCY 60Hz to 90Hz Frequency Response 5 Hz to 140kHz Working Voltage 9v to 16v DC Dimensions 7.25” x 1” x 2.25” Mounting Depth

Read more less

Specs:600 Watts Max Power per pair / 300 Watts each200 Watts RMS Power per pair / 100 Watts eachImpedance: 4 Ohm each tweeterSensitivity: 105 dBFrequency Response: 2,000 – 23,000HzAluminum Diaphragm with a 1″ voice coilRecommended High Pass Filter on TPT-SP4BT DSP, Based on Power per Tweeter7500 Hz under 150 Watts of Amplifier RMS Power with 18dB Slope6000 Hz under 100 Watts of Amplifier RMS Power with 12dB SlopeSizing:Mounting Depth: 1.39”Mounting Cutout Diameter: 2.87″ + TerminalsOverall Size: 3.85′ diameter x 1.75″ HeightWeight: 1.32 Lbs each tweeter

Read more less

GENERAL SPECIFICATIONS Nominal and Throat Diameter Low Freq. 8″ (203 mm) High Freq. 1″ (25.4mm) Nominal impedance 4 Ohm Nominal Power Handling* 190 Watts Continuous Program Power (RMS)** 380 Watts Max Peak Power*** 760 Watts Sensitivity 2.00V at 1m 97 dB Recommended Hi Pass Crossover For Full Power Handling 110 Hz 12db Per Octave Crossover Frequency Response 100 – 20,000Hz Voice Coil Diameter 1.5″ (38 mm) 1.0″(25mm) Voice Coil Wire Copper CCAW Voice Coil Winding Depth 8.0 mm N/A Former Material Kapton Kapton Magnetic Gap Depth 5.0 mm N/A Frame Material S. Steel Mylar

Read more less

GENERAL SPECIFICATIONS Nominal Diameter 8″ (203 mm) Nominal impedance 4 Ohm Nominal Power Handling 225 Watts Continuous Program Power (RMS) 450 Watts Max Peak Power 900 Watts Sensitivity 2.00V at 1m 93.5 dB Recommended Hi Pass Crossover** **For Full Power Handling 120 Hz** **12db Per Octave Crossover Frequency Response at -10dB 75 – 7,500 Hz Voice Coil Diameter 2″ (50 mm) Voice Coil Wire CCAW Voice Coil Winding Depth 12.0 mm Former Material Kapton Magnetic Gap Depth 6.0 mm Frame Material Stamped Steel

Read more less

GENERAL SPECIFICATIONS Nominal Diameter 8″ (203 mm) Nominal Impedance 8 Ohm Nominal Power Handling 350 Watts Continuous Program Power (RMS) 700 Watts Max Peak Power 1400 Watts Sensitivity 2.83V at 1m 97 dB Recommended Hi Pass Crossover *For Full Power Handling 95 Hz* *12db Per Octave Crossover Frequency Response 80 – 5,600 Hz Voice Coil Diameter 2.5″ (51 mm) Voice Coil Wire CCAW Voice Coil Winding Depth 11.0 mm Former Material Glass Fiber Magnetic Gap Depth 8.0 mm Frame Material Die Cast Aluminum

Read more less

GENERAL SPECIFICATIONS Nominal Diameter 8″ (203 mm) Nominal impedance 8 Ohms Rated AES Power Handling (RMS) 300 Watts Program Power 600 Watts Sensitivity 2.83V at 1m 98 dB Recommended Hi Pass Crossover****For Full Power Handling 160 Hz****12db Per Octave Crossover Frequency Response at -10dB 85 – 8,500 Hz Voice Coil Diameter 2.0″ (51 mm) Voice Coil Wire CCAW Voice Coil Winding Depth 14.5 mm Former Material Polyimide Magnetic Gap Depth 8.0 mm Frame Material Die cast aluminum

Read more less

GENERAL SPECIFICATIONS Nominal Diameter 8″ (203 mm) Nominal impedance 8 Ohm Nominal Power Handling 250 Watts Continuous Program Power (RMS) 500 Watts Max Peak Power 1000 Watts Sensitivity 2.83V at 1m 95 dB Recommended Hi Pass Crossover** **For Full Power Handling 95Hz** **12db Per Octave Crossover Frequency Response at -10DB 75 – 7,500 Hz Voice Coil Diameter 2″ (50 mm) Voice Coil Wire CCAW Voice Coil Winding Depth 12.0 mm Former Material Kapton Magnetic Gap Depth 6.0 mm Frame Material Stamped Steel

Read more less

GENERAL SPECIFICATIONS Nominal Diameter 8″ (203 mm) Nominal impedance 8 Ohm Nominal Power Handling* 350 Watts Continuous Program Power (RMS)** 700 Watts Max Peak Power*** 1400 Watts Sensitivity 2.83V at 1m 98 dB Recommended Hi Pass Crossover For Full Power Handling 95 Hz 12db Per Octave Crossover Frequency Response at -10dB 70 – 5,600 Hz Voice Coil Diameter 2.5″ (63 mm) Voice Coil Wire CCAW Voice Coil Winding Depth 11.3 mm Former Material Fiber Glass Magnetic Gap Depth 8.00 mm Frame Material Die Cast Aluminum

Read more less

GENERAL SPECIFICATIONS Nominal Diameter 8″ (203 mm) Nominal impedance 8 Ohm Nominal Power Handling 300 Watts Continuous Program Power (RMS) 600 Watts Max Peak Power 1200 Watts Sensitivity 2.83V at 1m 98.5 dB Recommended Hi Pass Crossover** **For Full Power Handling 145Hz** **12db Per Octave Crossover Frequency Response at -10DB 95 – 10,500 Hz Voice Coil Diameter 2″ (50 mm) Voice Coil Wire CCAW Voice Coil Winding Depth 11.0 mm Former Material Kapton Magnetic Gap Depth 7.0 mm Frame Material Die Cast Aluminum

Read more less

GENERAL SPECIFICATIONS Nominal Diameter 6″ (152 mm) Nominal impedance 4 Ohms Rated AES Power Handling (RMS) 100 Watts Program Power 200 Watts Sensitivity 2.83V at 1m 94 dB Recommended Hi Pass Crossover**For Full Power Handling 150 Hz****12db Per Octave Crossover Frequency Response at -10dB 155 – 11,000 Hz Voice Coil Diameter 1.5″ (38 mm) Voice Coil Wire Copper Voice Coil Winding Depth 8.0 mm Former Material Kapton Magnetic Gap Depth 5.5 mm Frame Material Stamped Steel

Read more less

GENERAL SPECIFICATIONS Nominal Diameter 6″ (152 mm) Nominal impedance 8 Ohms Rated AES Power Handling (RMS) 250 Watts Program Power 500 Watts Sensitivity 2.83V at 1m 96 dB Recommended Hi Pass Crossover****For Full Power Handling 220 Hz****12db Per Octave Crossover Frequency Response at -10dB 90 – 13,000 Hz Voice Coil Diameter 2″ (50 mm) Voice Coil Wire CCAW Voice Coil Winding Depth 11.2 mm Former Material Kapton Magnetic Gap Depth 5.5 mm Frame Material Die Cast Aluminum

Read more less

GENERAL SPECIFICATIONS Nominal and Throat Diameter Low Freq. 6.5″ (152 mm) High Freq. 1″ (25.4mm) Nominal impedance 4 Ohm Nominal Power Handling* 190 Watts Continuous Program Power (RMS)** 380 Watts Max Peak Power*** 760 Watts Sensitivity 2.00V at 1m 96 dB Recommended Hi Pass Crossover For Full Power Handling 120 Hz 12db Per Octave Crossover Frequency Response 100 – 20,000Hz Voice Coil Diameter 1.5″ (38 mm) 1.0″(25mm) Voice Coil Wire Copper CCAW Voice Coil Winding Depth 8.0 mm N/A Former Material Kapton Kapton Magnetic Gap Depth 5.0 mm N/A Frame Material S. Steel Mylar

Read more less
