Description
Enhance your audio setup with the BPS Audio 2" Exit Professional Compression Driver. Engineered to deliver exceptional performance, this compression driver is designed to withstand the demands of intense car audio competitions and provide superior sound quality. With a power handling of 200 watts and a frequency response range of 12,000 Hz to 18,500 Hz, it ensures every detail of your music is reproduced with stunning clarity and precision. Upgrade your sound system with the BPS Audio 2" Exit Professional Compression Driver and elevate your listening experience to new heights.
Description
Discover the ultimate in high-frequency audio reproduction with the best bullet super tweeter by BPS Audio. Engineered to deliver exceptional performance and clarity, this tweeter is a must-have for audio enthusiasts and professionals alike.
With an RMS power handling of 125 Watts and a program power of 250 Watts, this tweeter is capable of handling even the most demanding audio setups. Its high sensitivity rating of 107 dB ensures efficient power conversion, resulting in crisp and detailed sound reproduction.
Funciones
Diafragma fenólico de 2" para mayor durabilidad y respuesta extendida de frecuencia media a alta
Impedancia de 8 ohmios
Cámara de resonancia de aluminio
Imán de óxido de ferrita
El rango de frecuencia extendido coincide con todos los altavoces de rango medio
Montaje de 4 pernos
Compatible con todas las bocinas de guía de onda de garganta de 4 pernos y 2"
Funciones
Diafragma de titanio de 2" para mayor durabilidad y respuesta HF extendida
Impedancia de 8 ohmios
Cámara de resonancia de aluminio
Imán de óxido de ferrita
El rango de frecuencia extendido coincide con todos los altavoces de rango medio
Montaje de 4 pernos
Compatible con todas las bocinas de guía de onda de garganta de 4 pernos y 2"
Specs:600 Watts Max Power per pair / 300 Watts each200 Watts RMS Power per pair / 100 Watts eachImpedance: 4 Ohm each tweeterSensitivity: 105 dBFrequency Response: 2,000 – 23,000HzAluminum Diaphragm with a 1″ voice coilRecommended High Pass Filter on TPT-SP4BT DSP, Based on Power per Tweeter7500 Hz under 150 Watts of Amplifier RMS Power with 18dB Slope6000 Hz under 100 Watts of Amplifier RMS Power with 12dB SlopeSizing:Mounting Depth: 1.39”Mounting Cutout Diameter: 2.87″ + TerminalsOverall Size: 3.85′ diameter x 1.75″ HeightWeight: 1.32 Lbs each tweeter
GENERAL SPECIFICATIONS
Exit Throat Diameter
2” (50mm)
Nominal impedance
8 Ohm
Nominal Power Handling*
250 Watts
Continuous Program Power(RMS)**
500 Watts
Max Peak Power***
1000 Watts
Sensitivity 2.00V at 1m
110 dB
Recommended Hi Pass Crossover For Full Power Handling
600 Hz 12db/oct Crossover
Frequency Response at -10dB
450 – 7,000 Hz
Voice Coil Diameter
4” (101.6 mm)
Voice Coil Wire
CCAW
Voice Coil Former Material
Kapton
Diaphragm Material
Phenolic
Flux Density
1.95 T
Magnet Material
Neodymium
GENERAL SPECIFICATIONS
Exit Throat Diameter
2” (50 mm)
Nominal impedance
8 Ohm
Nominal Power Handling*
200 Watts
Continuous Program Power(RMS)**
400 Watts
Peak Power***
800 Watts
Sensitivity 2.83V at 1m
109 dB
Recommended Hi Pass Crossover For Full Power Handling
700 Hz 12db/oct Crossover
Frequency Response at -10dB
450 – 7,500 Hz
Voice Coil Diameter
4” (101.6 mm)
Voice Coil Wire
CCAW
Voice Coil Former Material
Kapton
Diaphragm Material
Phenolic
Flux Density
1.95 T
Magnet Material
Neodymium
